Specifications

n

n
• Motor: 72 Volt (DC Permanent Magnet)

n

• Rated Power: 3000 Watts

n

• Peak Power: 12,000 Watts

n

• Peak Torque: 65N

n

• Max Speed: 77mph (125km/h)

n

• 0-62 mph: 5 seconds (0kmh-100kmh)

n

• Battery: 72V 50Ah Lithium Ion (quick release)

n

• Recommended Age: 16+

n

• Max Rider Weight: 330 lbs (150kg)

n

• Peak Battery Voltage: 84V

n

• Continuous Output Current of Battery: 150A

n

• Peak Output Current of Battery: 300A

n

• Lithium Cell Type: CATL (Tesla Supplier)

n

• Transmission: 4 Speed Manual Clutch Foot Shift, 1 Reverse Gear

n

• Charging Time: 3 hours (15A Charger)

n

• Lights: LED

n

• Meter: LCD

n

• Wheelbase: 56 inches (1424mm)

n

• Seat Height: 35.4 inches (900mm)

n

• Ground Clearance: 12.5 inches (318mm)

n

• Brakes: Front & Rear Hydraulic Disc

n

• Brake Pads: Copper Base

n

• Shocks: MNT Single Cavity Double Adjustable

n

• Front Tire: 80/100-21

n

• Rear Tire: 110/90-18

n

• Rim & Hub: 7116 Alloy Rim, Casted Hub

n

• Frame: Metal Q345B+6061 Forged Aluminum Alloy

n

• Rear Fork: Aluminum Alloy

n

• Drive Chain: 520

n

• Handlebar/Clutch Lever: Aluminum Alloy

n

• Steering: Aluminum Alloy 7075

n

• Product Size: 84x33x48 inches (2120x840x1225mm)

n

• Product Weight: 238 lbs (108kg)

n

• Box Size: 62x33x18 inches

n

• Box Weight: 265 lbs

n

• Warranty: 6 months parts replacement
